In this sphere, energy is one of the vital things that can't be neglected. In fact, it is humanly impossible to talk about life without energy because energy is needed for almost every human activity, including tools that aid in carrying out the activities.
Imagine what life will be without lights, phones, or other modern gadgets that have made life easier and worth living. You can agree with me that without energy, modern life would have been a mere illusion.
All of that energy, however, comes at a cost. In reality, only used wind-powered ships to explore the New World. Even so, there are those that are given for free. These sources of energy are non-polluting and limitless.
They can, however, be used for a variety of purposes, including powering windmills for grinding corn, pumping water, and constructing electrical devices, motors, and so on.
In this article, you will get to understand the process of free energy creation in a pulse motor-generator. Read on!
What is A Free Energy Generator?
An engine-free energy generator is a simple system for generating electrical energy. It operates on the principle of Neodymium Magnets. However, Magnetic fields are formed in a simple motor by electric coils, which are usually Cu or Al coils.
READ ALSO: Bio septic tank and it's advantages in gas and fertilizer production
Note, these motors provide an electrical supply on a continuous basis in order to generate a magnetic field. There are massive energy losses. But the Magnet Motor consists of no such coils.
For several years, simple magnets have been used to generate electric power by using their magnetic field. They are mounted within the cores of motors and generators.
The magnetic effect is the fundamental theory of power generation. It says, "When a conductor is rotated in an electromagnetic field, a voltage is generated in the conductor."
What Motor Generator Consists?
A simple dc motor/generator consists of a rotor and a stator. The stator of the machine does not move and normally is the outer frame of the machine; the rotor is free to move and normally is the inner part of the machine.
To generate power, we must now rotate the shaft of the generator, which is accomplished by the use of Neodymium magnets mounted on the fan's fins.
These disc-shaped magnets are arranged in such a way that all of the north and south poles face the same direction, i.e., inwards or outwards.
A magnetic field is created by these magnets pointed upward. Following that, a bigger magnet is placed in front of these discs.
READ ALSO: Hydro Power Generation and Aquatic Life Protection
Understanding the Process of Free Energy Creation in a Pulse Motor Generator
The pulse motor-generator produces alternating current voltage. The input pulse current is routed through a specially placed input coil ironless (bobbin).
The control wheel is made up of a fidget spinner with iron inserts and three N-N-N neodymium magnet disks. The reed switch is located on the input coil of the pulse motor-generator, which is operated by two small solar panels. The reed switch is turned on.
Bringing a magnet close to the reed switch activates it. When the magnet is removed from the switch, the reed switch returns to its original location.
Here are the tools and materials used to build a pulse motor Generator:
1. Neodymium Magnet Discs (3)
One of the important materials needed in build a pulse motor-generator is Neodymium Magnet Disc also known as NdFeb or NIB.
They are among the powerful rare-earth magnets available in the world. The material is available in disc and cylinder shapes and they have magnetic properties that far exceed all other permanent magnet materials. For motor-generator building, three (3) of these discs are needed.
2. Fidget Spinner
This is a toy that is made up of a ball bearing in the center of a multi-lobed. This type of spinner is unique because it is made of durable metal that is anti-tangle and anti-roll. For the building of a motor-generator, it is called a flywheel.
READ ALSO: Autonomous Mini Hybrid Hydro Power Plant
3. Solar Panels (Two small panels)
Two small solar panels are needed for the power supply. The following is the required specification for the recommended solar panels:
Voltage: 5V
Power: 1.2W
Current: 240 mA
Material: Monocrystalline
Size: 110 x 69mm
4. Step-up Module with adjustable booster power supply module
• AeroSemi MT3608 1.2MHz 2A Step-Up Converter
• 2A maximum output current
• 2.0 to 24VDC input voltage range
• 28V maximum output voltage (trimpot adjustable)
• 93% peak efficiency (~200mA output current at 5Vin, 12Vout)
• 36 x 17 x 14mm
5. Coil Iron
Building a motor-generator requires the use of coil iron which is used to capture the magnetic flux generated by the pulse motor
Note, not any kind of coil iron. To be more specific, the iron must be less from synchronous motor 230 V.
6. Bobbin
A motor bobbin is a body component around which a coil is wound. The bobbin is made up of a molded resin article made from a polymer with amide linkages. It can handle improved efficiency and power output of a motor-generator or similar device.
When the winding generator bobbin coil in switched-mode power supplies as an energy storage device to produce DC electric current.
7. Reed switch
The reed switch is an electrical switch operated by an applied magnetic field. It is used to control the flow of electricity in a circuit. The switching mechanism is made up of two ferromagnetic blades, separated by only a few microns.
In Conclusion
With this material and process, you can build a pulse motor-generator.
